L3Harris
The XL-185M delivers crystal-clear audio with advanced noise cancellation technology, intuitive ease of use, rugged performance that meets MIL-STD-180G compliance and more ways to connect.
Frequency Band:
VHF, UHF, 700/800, 900 MHz
Frequency Range:
VHF: 136-174 MHz
UHF: 378-522 MHz
700/800: 768-776, 798-806, 806-816, 851-861 MHz
900: 896-902, 935-944
Power Output:
VHF: 50 W
UHF: 50 W
763 – 776, 793 - 806: 30 W
806 - 825, 851 - 870: 35 W
896-901, 935-944: 35 W
Number of Channels/Groups/Zones:
Channel spacing:
12.5, 25
Dimensions H x W x D
Radio Only: 2.0 x 6.9 x 9.7 in (49 x 174 x 230.5 mm)
Radio and Control Unit (includes knobs): 2.4 x 6.9 x 12.8 in (60 x 175 x 320.7 mm)
Control Unit (Remote) (includes knobs): 2.4 x 6.9 x 4.0 in (60 x 175 x 72.2mm)
Weight
Remote Mount Radio: 5.0 lbs (2.3 kg)
Control Unit (Remote Mount): 1.3 lbs (0.6 kg)
Front Mount Radio with Control Unit: 7.0 lbs (3.2 kg)
Keypad / Keys
8 programmable buttons
Display
18-bit color LCD
480 pixels x 220 pixels
3.3-inch color LCD with up to 3 lines of text
Operating temperature
-22 to +140°F (-30 to 60°C)
Mil spec
810D, E, F, G
IP Standards
IP65 (Control Unit)
LTE-capable mobile for First Responder and Utility Communications
The XL-185M features an intuitive interface and high-visibility color display, allowing users to stay more focused on the job, less on the radio. A modular design also offers flexible mounting configurations for a variety of vehicles. The XL-185M connects in more places and comes standard with Wi-Fi®, Bluetooth® and GPS. The XL-185M transforms your vehicle into an on-the-go communications hub with the addition of field upgradeable LTE* and broadband connectivity providing hot spot capabilities that allow you to stay connected through an LMR or LTE network.
Key Benefits:
For more information on accessories, please Contact Us
